ACS ACM1552U NFC USB Upgrade Module for Zebra ZT610
- Quantity Unit Price
- 1+ $572.00
| Product | Reader/Writer |
|---|---|
| Manufacturer | Advanced Card Systems |
| Country of Manufacture | United States |
| Shipment Origin | United States |
| Harmonized Tariff Code | 8471.60.90 (Input or Output Unit) |
| Availability | Normally Stocked |
| Lead Time | Immediate |
| Minimum Order Quantity | 1 |
| Color | White |
| Tag Technology | NFC |
| Frequency | 13.56 MHz (NFC) |
| Compliance | CE, FCC, REACH, RoHS |
| Connection | USB 2.0 (Type A) |
| Features | Buzzer, Firmware Upgradable, Lights, NFC |
| Power | USB |
| NFC Mode | Card Emulation, Keyboard Emulation, Tag Reader/Writer |
| NFC Standards | ISO 14443 Type A, ISO 14443 Type B, ISO 15693, ISO 18092, MIFARE, FeliCa, PC/SC, NFC Forum - Type 1, NFC Forum - Type 2, NFC Forum - Type 3, NFC Forum - Type 4, NFC Forum - Type 5 |
| Operating System | Android, Linux, Mac, Windows |
| Operating Temperature | 0° C to 60° C |
| Shelf Life | 10+ Years @ 23° C, 50% RH |
Files relating to Store products, GoToTags software and general Connected Things technology can be downloaded from the public GoToTags GitLab project.
- Artwork Templates – premade artwork templates for custom-printed products
- Encoding Data – files to provide data for tag encoding services
- NFC – technical specifications for NFC chip types, reader, NDEF, ...
- UHF RFID – technical specifications for UHF RFID chip types, readers, ...
- Products – additional information about Store products
If you cannot find the document you are looking for contact us.
The ACS ACM1552U NFC USB Upgrade Module for Zebra ZT610 adds NFC read/write capability directly to your Zebra ZT610 industrial label printer. The module includes a plastic media roller that replaces the standard metal roller, enabling NFC tag encoding as labels pass through the print path.
Based on 13.56 MHz contactless technology, the ACM1552U module supports contactless cards and devices following the ISO 14443, ISO 15693, and ISO 18092 standards. It is CCID & PC/SC compliant and supports high-speed communication for contactless cards at a maximum of 848 kbps. The module also supports three NFC modes:
- Smart Card Reader/Writer
- Card Emulation
- Keyboard Emulation - (tool download)
The ACM1552U connects to the Zebra ZT610 via USB, making it compatible with standard NFC encoding software and workflows without additional drivers or custom integration work.
Features
- Designed for Zebra ZT610 industrial label printers
- Includes plastic media roller to replace standard metal roller
- USB 2.0 Full Speed Interface
- CCID Compliance
- Contactless Smart Card Support:
- Read/Write speed up to 848 kbps
- Built-in antenna for contactless tag access, with card reading distance of up to 70 mm (depending on tag type)
- Supports ISO 14443 Type A and B cards, ISO 15693 Cards, and ISO18092 NFC
- Supports MIFARE Classic®, MIFARE®, DESFire®, MIFARE Ultralight®, MIFARE Plus®, FeliCa, and Topaz
- Built-in anti-collision feature
- Supports extended APDU (max. 64 kbytes)
- NFC Support:
- Smart Card Reader/Writer Mode
- Card Emulation Mode
- Keyboard Emulation Mode
- Application Programming Interface:
- Supports PC/SC
- Supports CT-API (through wrapper on top of PC/SC)
- Peripherals:
- User-controllable bi-color LED (Blue & Green)
- USB Firmware Upgradability
